UNIMAK FULLY AUTOMATED 60" PANEL LAMINATION LINE complete with AUTO LOADING AND UNLOADING

System includes a complete Unimak Flat Panel Lamination Line designed for laminating high quality rigid, panels up to 60 inches wide. The system was installed, commissioned, and lightly used, with 135 operating hours on major components. The equipment is fully functional and in like-new condition and currently under power. Full line documentation and detailed specifications available upon request.

The package includes all primary machinery, conveyors, safety fencing, catwalks, vacuum handling systems, and supporting equipment required for a turnkey lamination operation.

PRODUCTION SPECIFICATIONS

• Panel Width             11.8”- 60" (300mm -1,524 mm)
• Panel Thickness       0.118” - 2.36" (3 mm-60 mm
• Panel Length            19.68”-96" (500 mm – 2438 mm)
• Panel Weight            220lbs (100 Kg)
• Production Speed     5–25 m/min (adjustable)
• Max Throughput       8 panels/min (varies by size and conveyor distance)
• Working Height        35.4" (900mm)
• Panel Types              MDF, HDF, Chipboard, Door Leaf (sanded),                                                 Polystyrene, Styrofoam, XPS Sandwich Panels
• Foil Types                 PVC, High Gloss, Acrylic, ABS, PP, PET, Finish Foil,                                       CPL, Laminate, Natural Veneer, Sheet or Roll                                  laminates
• Glue System              PUR — HOT MELT (drum melter included)
• Floor Space Req        88' × 29' (2,552 sq ft) HT 181" (approx. 15 ft)
• Loading/Unloading   Forklift platforms (included)
• Overhead Crane        3-axis, 500 kg capacity, rails included

LINE EXECUTION

1. Auto Loading, Dual Zone Vacuum DeStacker
2. Substrate Top/Bottom "Sword Style" Panel Cleaner
3. Substrate Pre Heat Panel Heater
4. PUR Hot Melt Glue Spreader (with Melter/Unloader)
5. Foil Laminator w/ Auto Splicing and Press                                                   * Overhead Foil and Protective Film Supply Mezzanine
6. Protective Film Applicator
7. Auto Edge Trim and Flying Cross Cut Trim Conveyor
8. Cool Down Conveyor
9. Auto Unloading - 3 Zone Vacuum DeStacker
