SAC CS40 Sliding Table Panel Saw
A really nice unit. Ready to ship!
MA ID: | PSS - 12608 |
Status: | Sold |
Price: | $5,500.00 |
Category: |
Panel Saw - Sliding |
Manufacturer: | SAC |
Model: | CS40 |
Condition: | Very Good |
SAC CS40 Panel Saw
CALL FOR AVAILABILITY
utting length; 3,200 mm (126") Anodized aluminum sliding table 13" x 131", locks for easy panel loading in any position Main saw arbor, (30 mm) and has 45° Tilting Blade diameter; 400 mm (16") 130 mm (5.1") max. cut height @ 90° - 100 mm (3.9") @ 45°; 1,500 mm (59") rip cap. Main saw ; 9 HP self-braking motor, w/ (3) cutting speeds 2,600 - 4,000 & 5,600 rpm 1.0 HP scoring saw motor. 120 mm (5") Dia. scoring blade - 8,000 RPM scoring unit w/external adjustment, electric raise & lower of main blade.
Square crosscut fence with (2) stops, extension table with miter fence & sliding outrigger support.
Better photos coming
|
|
Shipping Footprint: | 14 (length) x 8 (width) x 8 (height) |
Weight: | 2500 lbs |
