SAC CS40 Sliding Table Panel Saw

A really nice unit. Ready to ship!

MA ID: PSS-12608
Price: $5,500.00 -or- as low as $111.15/mo.*
General Location: North East
Category:

Panel Saw - Sliding

Manufacturer: SAC
Model: CS40
Condition: Very Good
SAC CS40 Panel Saw

Cutting length; 3,200 mm (126")

Anodized aluminum sliding table 13" x 131", locks for easy panel loading in any position

Main saw arbor,  (30 mm)  and has 45° Tilting

Blade diameter; 400 mm (16")

130 mm (5.1") max. cut height @ 90° - 100 mm (3.9") @ 45°; 1,500 mm (59") rip cap.

Main saw ; 9 HP self-braking motor, w/ (3) cutting speeds 2,600 - 4,000 & 5,600 rpm

1.0 HP scoring saw motor.

120 mm (5") Dia. scoring blade - 8,000 RPM scoring unit w/external adjustment, electric raise & lower of main blade.



Square crosscut fence with (2) stops, extension table with miter fence & sliding outrigger support.





Better photos coming



Shipping Footprint: 14 (length) x 8 (width) x 8 (height)
Weight: 2500 lbs
Rigger: Not Required
