BIESSE REGAL 3 HEAD 52" WIDE BELT SANDER

BIESSE REGAL 3 HEAD 52" WIDE BELT SANDER

MA ID: SWM - 12521
Price: Call For Price
Category:

Wide belt and drum (Multi contact)

Manufacturer: Biesse
Model: 330-1350
Year of Manufacture: 2005
Condition: Good
Electric: 460 Voltage 60 Cycle 3 Phase

Working width: 53" x 7.8"

Heads: Solid Steel Drum, Rubber Covered Drum, Rubber covered drum. 1st Head: 250 mm dia. Grooved Steel roller 30 HP motor.
2nd Head: 250 Calibrating/Sanding roller with 65 Shore rubber coating 25 HP motor. 3rd Head: Third operating unit equipped with Rubber Covered Roller with 45 Shore and 24-Section Segmented platen, 20 HP motor. All heads with Sanding belt air jet cleaning. Belt length 103".

Operating controls: EasyPro 1000 Electronic Control unit. It displays Working thickness and feed speed, Delays and advances for timed operations. The sectors engaged to the right and left of the panel. It manages a sectioned electronic pad, including the switching on and off of one or more sectors on the right or left of the panel, and the timed operation of one entire work unit. Recognition of de-frames pieces.

Feed: Feed belt speed 5/10 MPM (16.5 - 33 FPM), 60 Shore rubber belt.  Two-speed gear motor 1.1 kW (1.5 HP) feed drive; automatic conveyor belt tracking.  Dust extraction hood 160 mm (6.3") diameter.


Shipping Footprint: 72" (length) x 72" (width) x 84" (height)
Weight: 8500 lbs
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
