- Very good condition, completely cleaned and checked, replaced VFD and bearing block.
- 460 Volt, 3 Phase, 60Hz, 50 Amp
Specifications: - 53” wide capacity
- 2” Thickness capacity
- Motor for sanding rollers, 2 @ 2.5 kW (3.4 HP)
- First unit: 16” diameter rotating brush sanding roller (11” core) with 56 helical grooves, variable speed (10 – 300 RPM), clockwise/counter-clockwise rotation and separate motorized height adjustment
- Second unit: 16” diameter rotating brush sanding roller (11” core) with 56 helical grooves, variable speed (10 – 300 RPM), clockwise/counterclockwise rotation and separate motorized height adjustment
- Third unit: 11 @ 10” diameter rotating sanding discs with 24, 3” grooves mounted on a disc station that oscillates from left to right with separate height adjustment of the disc-station (to run discs only or rollers only or everything together)
- Motor for disc station, 2.5 kW (3.4 HP), 50 – 300 RPM with clockwise and counter-clockwise rotation
- Motor for disc station oscillation: 0.5 kW (0.67 HP) at 10 – 60 RPM
- 10” Diameter panel cleaning brush with 2.5 kW (3.4 HP) motor at 50 – 150 RPM controlled by separate potentiometer
- Pneumatic blow off station timed to run only when material is under unit
- Vacuum bed conveyor belt with 7.5 kW (10 HP) vacuum motor
- Feed belt with 1.8 kW (2.4 HP) variable speed motor
- Separate variable RPM adjustments for discs and rollers
- Motorized thickness adjustment
- 5 Spring loaded hold down rollers
- Motorized height adjustment of hold down rollers
- PLC with 10” color HMI touchscreen
- Eight 4” diameter dust outlets on top of machine
- Vacuum blower outlet on end of machine has a 200 mm (7.9”) outlet
- Switch manual/automatic (start machine from control panel or from finishing line)
Technical Data: Max. working width | 1350mm (53”) | Max. thickness of work piece | 200mm (2”) | Motor disc station | 2.5 kW (3.4 HP), 50 - 300 RPM | Motor disc station oscillation | 0.5 kW (0.67 HP), 10 – 60 RPM | Motor sanding rollers | 2 @ 2.5 kW, 10 – 300 RPM | Diameter sanding roller | Max. 400mm (max. 16”) | Motor feed belt | 1.8 kW (2.4 HP) 6 – 40 FPM | Motor vacuum bed | 7.5 kW (10 HP) | Voltage | 460 V, 3 PH, 60 Hz, 50 Amp | Weight | 7,700 lbs | Length/Width/Height | 109.4” x 78.7” x 83” |
US standards in measurement are an approximation Ready for van freight, prep for flatbed trailer - $150.00
|
