Brandt KDN-540-2C
MA ID: | EBS - 10355 |
Status: | Archived |
Price: | $18,500.00 |
Category: |
Edgebanders -Single Sided |
Manufacturer: | Brandt |
Model: | KDN-540-2C |
Year of Manufacture: | 2004 |
Condition: | Good |
3-7-19 Still available
Brandt KDN-540-2C Servo Edge Bander
0.4 - 8 mm (1/64" - 5/16") Edge capacity, Panel thickness 12 - 55 mm (1/2" - 2-3/16"), Minimum panel length 160 mm (6-3/8") and 65 mm (2-1/2") minimum width Equipped with Integrated Line control - No limit switches used for setting workstation function Open Station for Joint Trimming Unit for pre-trimming of the workpiece prior to gluing Universal Automatic Magazine for Strip and Coil Feeding with strengthened precutter for cutting PVC from the coil - 800 mm Diameter coil table for large 3 mm PVC coils Glue Station - Quick heat up Granulate Gluing System, includes reversible rotation of glue application roller; Pressure Section with (1) large driven pressure roller and (2) secondary roller with controlled side pressure Double Motor End trim Station - Straight-Chamfer 0 to 15° - (2) 1/4 HP - 12,000 RPM motors; program controlled indexing from straight to bevel end trimming Flush Trimming Unit - (2) 3/4 HP - 12,000 RPM motors with 2-Position Vertical Positioning Fine Trimming Station - (2) 3/4 HP - 12,000 RPM motors; Servo Motor Program controlled indexing Contour Trimming Unit - (1) ½ HP - 12,000 RPM motor; For corner rounding of thick PVC Edges Scraping Station with Knives - For scraping of roughly trimmed PVC edges in order to remove cutter marks; program controlled pneumatic indexing Top & bottom buffing Station - inclinable vertically and horizontally Feed chain track speed - (2) Speeds: 36 FPM when contour trimming, otherwise 46 FPM; 3 HP feed drive Equipped with digital height indicator, Electronic Frequency Changer for all trimming motors |
Please confirm all data before committing to a purchase.
