Tenoners > Tenoner - Single end

BALESTRINI MICRON TENENOR

BALESTRINI MICRON TENENOR

MA ID: TN1-11397
Price: $9,495.00 -or- as low as $191.89/mo.*
General Location: Midwest
Category:

Tenoner - Single end

Manufacturer: Balestrini
Model: MICRON
Condition: Good
Electric 230 volt, 60 cycle, 3 phase
Twin table design with (1) spindle per side; spindle has variable speed on oscillation stroke; tables have air over oil variable speed feed rate; (1) pneumatic hold down clamp per table. 500-800 slots per hour



Working dims.: Max cross sect. 5.91" x 5.91"; min. cross sect.: 0.59" x 0.59".

Slot dimensions: Length max. 4.72"; dept max.2.36".

Bit dimensions: max. 1-1/8"

Motor: 3 HP spindle motor producing a spindle speed of 9,000 RPM; 1 HP oscillation motor; oscillating speeds of 120 to 240 strokes per minute.

Shipping Footprint: 4 (length) x 4 (width) x 5 (height)
Weight: 1500 lbs
Rigger: Not Required
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
