16in Northtech Long Bed Jointer

16" wide long bed jointer with helical cutter head

MA ID: JT-11856
Price: Call For Price
General Location: North East
Category:

Jointers

Manufacturer: Northtech
Model: 1284HC-532
Year of Manufacture: 2019
Condition: New
Electric 230 volt, 60 cycle, 3 phase
Northtech 16" longbed jointer with helical cutter head

Available machine width of 12" or 16".

Bed way length is standard at 96" on 16" model.

Helical cutterhead is configured with 6 rows of 30 x 12 x 1.5 carbide 2 sided insert knives.

Dynamically balanced cutterheads are precision fitted with class 5 NSK sealed bearings.

Parallelogram designed bed ways provides quick and accurate adjustment of infeed/outfeed beds vs. older style jack screw and hand wheel system via cam and lever action. * Parallelogram design also facilitates the infeed table being in close proximity to the cutterhead, ensuring vibration free cutting and excellent chip removal characteristics via the cam and lever handle.

Machine bed ways are heat treated, precision ground and highly polished for incredible end to end and side to fence tolerances.

Center mount fence system employs a rack and pinion movement for quick and accurate positioning.

Noise abatement fingers are precision ground on table edges surrounding cutterheads improving sound decibel levels by over 25%.

Motors are started and protected via magnetic controls with overloads / on-off control is remote and located above the infeed table.

Oversized guard is standard providing optimum operator protection (spring loaded and adjustable tensioning).

Weight on 16" model . . . 956 lbs.

Warranty is one year parts

All machines are tested stateside prior to shipment providing trouble free start up.

Amp Requirement = 14 Amps

Total Hp. = 5 Hp.

Electronics = UL Approved Components

Dual Voltage = 230/460 Volt

Control Voltage = 220V Control Voltage

Pass-Line = 32''

Min. Length = 12'' With Push Block

Min. Width = 3'' With Push Block

Max. Width = 12''

Min. Thickness =

Cutter Head RPM = 5000 RPM

Head Type = Dynamically Balanced Helical Head

Cutter Head Dim = 4'' x 12''

Cut Head Matl. = Alloy Steel

Rows of Cutters = 6 Rows

No. of Inserts = 42 Inserts

Insert Size = 30 x 12 x 1.5 mm

Dust Collection = (1) 5'' @ 681 CFM

Guarding = Swivel Guard

Fence Dims. = 5-3/8'' x 47''

Frame Const. = Cast Construction

Infeed Table = 47-1/4''

Outfeed Table = 47-1/4''

Decible Rating = 69 dB

Shipping Footprint: 90 (length) x 34 (width) x 41 (height)
Weight: 1078 lbs
Rigger: Not Required
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
